The Rindo, Japanese for “remote forest road” applies our aerodynamic expertise to gravel racing and mixed terrain adventure. Sure, the Rindo is a gravel bike, but not just any gravel bike. It is, in fact, exactly the kind of gravel bike you would expect from Ceepo: a race-oriented carbon aero gravel superbike designed to go fast over a variety of terrain regardless of the conditions.

The Rindo’s ground up design inherits the aero road bike frame profile and total cable integration of the Stinger and Mamba R, while adding terrain versatility by accepting both 700c and 650b wheelset combinations, with a maximum clearance up to 700x45mm and 650bx2.1.



Tube shapes are robust but retain signature Ceepo aero features to keep it in the “aero is everything” family., such as the airfoil downtube and an integrated front end.  No reason a bike meant for the dirt can’t have an aero edge.

A cable free front end is utilitarian as well, uncluttered, easy for installing frame bags and free of any spaghetti tangle to snag on branches.  The clean lines of an aero superbike, but rugged for the backcountry.

Rindo retains the lightness and nimbleness found across the aero bike line, but fortifies the carbon chassis with stiffness where it is needed and weight savings where it counts to create a durable, stable and confident gravel platform. The tapered fork features full carbon construction based around a 160mm flat mount rotor.



On the point of terrain, with a longer wheelbase for stability and a dropped chain stay for wider tires, the Rindo is quite capable at pavement transitions, loose, hardpacked and rutted gravel, woodland trails, double track, dry river beds and even light single track. Go anywhere. Ride anything. From the pavement to where the dirt roads never end.

Screen Shot 2021-09-12 at 9.00.11 AM.png

Aero Tubes

Elegant aero tube shapes take advantage of truncated airfoils which allow the Ceepo to seamlessly combine greater aerodynamics to reduce drag and headwind turbulence while retaining competitive stiffness and weight values.

Screen Shot 2021-09-12 at 9.01.44 AM.png

Integration

Hidden Cable Pathways for total front end aero integration. With internal cable routing and cable free pathway solutions via partnerships with FSA and Token, Ceepo creates clean and aero front ends that smooth air flow, reduce drag and headwind turbulence. For some models, the clean lines create a snag free frame interface for attaching frame bags for long haul adventures.

One-Piece fork.png

One-Piece Fork

Integrates with the frame to create a single contiguous profile improving airflow. Flattened wide legs reduce form factors, narrow towards the axle for stability; reducing drag and turbulence, especially in headwind conditions; provide precision handling with a balanced weight to stiffness ratio. The crown tail further smooths airflow over the bike.

Screen Shot 2021-09-12 at 9.01.44 AM.png

Integration

Hidden Cable Pathways for total front end aero integration. With internal cable routing and cable free pathway solutions via partnerships with FSA and Token, Ceepo creates clean and aero front ends that smooth air flow, reduce drag and headwind turbulence. For some models, the clean lines create a snag free frame interface for attaching frame bags for long haul adventures.

Screen Shot 2021-09-12 at 9.00.20 AM.png

One-Piece Fork

Integrates with the frame to create a single contiguous profile improving airflow. Flattened wide legs reduce form factors, narrow towards the axle for stability; reducing drag and turbulence, especially in headwind conditions; provide precision handling with a balanced weight to stiffness ratio. The crown tail further smooths airflow over the bike.


Sizing Chart


Catalog

All new, all aero, all carbon combining triathlon and aero road bike design, Token Cable Box integration, increased carry capacity, wide tire clearance + 700 and 650 wheel versatility for a rugged race-oriented, all gravel + adventure superbike. Cable free, sleek can clean from pavement to gravel race to adventure overnights. Aero. Anywhere.

Groupset Compatibility:

Industry wide compatibility with mechanical and electronic 2x and 1x systems, including, but not limited to:

Shimano di2

SRAM eTap AXS

FSA K-Force WE

Classified PowerShift Hub

Colors: Arashi Gray



High-modulus Toray carbon 1020g (M)

One-Piece Adventure fork 450g



Rindo Adventure Fork:

One-piece high-performance fork with 60mm rake above, balancing stiffness with improved strength, yet compliant, and responsive.Rugged. Stable. Confident.



Cable Integration:

Full or semi integration cable solution. Aero, easy to maintain, wide handlebar compatibility. Cable free aerodynamics means fast clean lines, but also a snag free frame and easy frame bag installation.



XS/S - 90mm, M - 100mm, L - 110mm Sleek, refined with snag free clean lines



Geometry:

A fast and precise aero gravel bike, built for confidence and acceleration over rough terrain; dropped chainstay for wide tire clearance, 1x and 2x crankset and dropper compatible. All Aero. All day. All conditions.



Cable Routing:

Industry wide mechanical and electronic compatibility.

Capacity:

3 water bottle mounts; top tube mount; large frame space.

Aero Tubes:

Inherits the truncated airfoils from Stinger and Mamba for a streamlined aero profile balancing weight, handling, precision and stiffness, yet rugged and dependable.



Tire Clearance:

Up to 700x45mm or 650x2.1



BB Type BB386:

Dependable, smooth, durable, light, stiff, enhanced power transfer with industry wide crankset compatibility, from road 1x to 2x compact or sub-compact.

Seatpost:

Rough terrain compliant carbon seatpost for wide range compatibility; dropper compatible

Size: 27.2



Brakes:

Flat Mount: industry wide compatibility



Rotor Clearance Thru-Axle:

F: 160mm Max F: 100/12

R: 160mm Max R: 142/12



Headset:

1.5” - 1.5” integrated stem and headset is an elegant and logical cable integration solution.



Crankset: Max/Min:

2x 50/34; min 46/30; 1x max 53T, min 30T

Frame:

High-modulus Toray carbon 1020g (M, Naked)

One-Piece Adventure fork 450g (Uncut)
